In the range of vertical splitting machines, the DV-PRO-900is a stand-out, ultra-high performance and versatile machine designed for firewood producers who are seeking a solution capable of processing logs with diameters ranging from 20 to 90 cm. In addition, kindling can also be produced with any of the machines from the DV-PRO range.

Two versions to meet all requirements:
DV-PRO-900-T: Equipped with a feed belt with a double lug chain, this model conveys the log towards a saw, which can be:
A chainsaw
OR
A 130 cm diameter circular saw combined with a chainsaw

As an option, a hydraulic stop can measure the log and therefore optimise woodscrap management.

DV-PRO-900-P: Equipped with a trough on a push-pull rod, this model guarantees speed and efficiency. When the end of the log is almost reached, the push-pull rod automatically moves backwards, the trough descends and the next log is put into position while the previous log is still being sawn. Thanks to an automatic measuring system, the length of the logs is optimised, thus reducing losses.
This model is equipped as standard with a 130 cm circular saw combined with a chainsaw.

Versatility and performance assured

Productivity: the DV-PRO-900 is designed to process large quantities of wood within a short time, ideal for industries and large-scale production operations.

Robustness: its design guarantees optimal resistance to the most demanding operating conditions.

Power: our hydraulic power packs developed in-house guarantee high production rates, accompanied by motors sourced from major manufacturers.

Advanced automation: smart systems limit end-of-stroke losses and guarantee end products sized according to your requirements.

Remote management: any anomalies that occur are detected rapidly by an integrated system, thus facilitating maintenance and reactivity.

Optimal safety: full automation of the DV-PRO-900 provides reinforced protection for operators and accessories.

Personalisation: do you need to process longer logs, disentangle logs, or include a control pod? Each component of the system can be modified to meet your specific requirements.

Technical data
Wood diameter:From 20 to 90 cm
Length of logs: From 10 to 50 cm
Cutting system: Chain or chain + circular
Splitting: Vertical 40T
Commands: Automatic
Drive: Electric
Kindling production: Yes
Wood loading system: 15 mm steel feed belt
Wood holding system in the saw: Hydraulic clamps
Wood holding system in the splitter: Hydraulic press
Cutters: 2 cross-cut blades in wear-resistant steel
Type of chain: 3/4 11H
Type of circular saw: Carbide blade
Splitter actuators: 200 to 300 bars
Motor power: 55 kW min.
Oil volume: 900L min.
Electric: General PLC + safety relay or safety PLC
Oil flow rate: From 210 to 360
OPTION
Multi-guillotine system
OPTION
Remote control
OPTION
Push-pull rod for length adjustment on the feed belt
